名称：x-ray 价格：面议
modes 2d and 3d operation
throughput: 4 to .5 sq. in./sec
maximum board size: up to 20.” x 18.” (508mm x 450mm)
clearance: up to 2.” (50mm) top and 1.” (25mm) bottom
minimum component size: 01005
defects detected: part: position, missing, wrong, skew, tombstone
lead: bent, lifted, bridging
solder: open, insufficient, short, solder balls
bga: shorts, voids, position, missing ball
software
data requirements: ascii text, ndf pin data
cad translation package: excel, aegis, unicam, ndf translator, yt translator
programming skill level: technician or operator
operating system: windows xp professional
off-line software: optional - rework, review and program creation
spc software: optional - real-time local and remote monitoring of first
pass yield, defect trends, and machine utilization.
hardware
x-ray tube: maintenance free, sealed reflection target, 5 micron spot size
100 or 130 kv, 20 to 39-watt max. output
color camera: barcodes and fids
